EMERGENCY PREPAREDNESS & PROCEDURES
LIFE SAFETY EQUIPMENT
University Circle is a multiple use facility. It has three office buildings, a parking structure, and a hotel. Building 1900 was completed in November 2001, Building 2000 was completed in February 2002, and Building 1950 was completed in the Spring of 2003. The Four Seasons Hotel was completed in January 2006. Each building (1900, 1950, 2000) has six floors and one basement (parking) and has approximately 165,000 rentable square footage. All are equipped with modern life-safety systems. This includes a sprinkler system with flow detectors, smoke detectors, fire pull stations, pressurized stairwells and an elevator recall system. Sprinkler Systems University Circle has an automatic sprinkler system. Quick-response sprinkler heads will open in response to temperatures above 165 degrees. Activation of any sprinkler head will sound an alarm in the building and will summon security and the fire department. Two diesel fire pumps provide system pressure. Fire Alarm and Smoke Detection Fire alarm pull stations are located by stairwells and elevator lobbies. Smoke detectors are located throughout the building. Activation will send an audio/visual signal to the fire control room identifying the location and cause of the alarm. An alarm will sound in the building, and the alarm will be transmitted to an alarm monitoring company, which will also make contact with the fire department. Any tenant noting a fire condition should also call 9-1-1 directly and/or activate an emergency fire pull station. Lobby Door Release System Certain doors surrounding the elevator lobbies and located in fire-rated walls are equipped with magnetic hold-open devices. If a smoke detector on the floor is tripped, these devices will release the doors on that floor, impeding the spread of fire and/or smoke. Elevator Recall and Emergency Service There are three passenger elevators in each building servicing the basement though the sixth floors. Elevators are a dangerous place to be in a fire. The heat and damage caused by a fire can register a false "call" on the fire floor, causing the elevators to come to that floor. Accordingly, the following systems have been installed to protect persons using or attempting to use the elevators during a fire: Automatic Recall: In the elevator lobbies there are smoke detectors that activates this system. If any of these devices sense smoke, all elevators will close doors and return to the ground floor, where they will remain with doors open, until released by building or fire department personnel. | Emergency (Firemen's) Service: After an elevator recall has occurred, the elevators may be put into emergency service by using a key switch located in each car. This will allow operation of the car by using the "open door" and "close door" control buttons. This service is for use by the fire department for purposes of evacuation of disabled persons and for firefighting. Elevator Earthquake Response: When a moderate or severe earthquake occurs, a device on each elevator car senses the side-to-side motion of the car. If this motion exceeds a preset maximum, the elevator stops. It then moves in the opposite direction from its counterweight, stops at the next floor, and opens its doors. It will remain in this condition until it is thoroughly examined and put back into service by an elevator mechanic. Stairwells There are two stairwells that extend from the basement to the sixth floor of the building. The stairwell doors are fire rated at one and one-half hours. In an emergency scenario, exit signs can be followed directly to the nearest stairwell. Emergency Power Each building has an emergence diesel generator which will switch on automatically in the event of power failure. The generators power one elevator at a time, building life safety systems, and emergency lighting. Extinguishers ABC fire extinguishers are located throughout the building and are inspected annually. Standpipes A standpipe is a type of water piping system which fire hoses can be connected, allowing manual application of water to the fire. They are located in the building stairwells. Life Safety Control Room The Life Safety Control Room is located in the basement level of Building 1900. It contains annunciator panels showing alarm or system fault locations, the main panel for all buildings, security cameras and is staffed 24 hours a day, seven days a week. |
UTILITY SHUT OFF
Building 1900
Building 1950
| Building 2000
|
EMERGENCY ACTION PLAN
This plan is a tool designed to assist you before and in an emergency. Familiarize yourself with your workplace environment, the people who work there, the University Circle’s and your company’s emergency preparations and procedures. Take precautions necessary to provide for the services mentioned in this book and test them before you need them. Every situation is different which means your response will have to differ. This is not a substitute for common sense. If you have a question, suggestion, or concerns contact your manager. Discuss the contents of this plan with your co-workers. Have a rehearsal and walk through the procedures. Even the best actors cannot perform well without time to rehearse the script. Always use your initiative, intuition and good judgment to assure your own personal safety. EVACUATION/FIRE DRILLSYou may become aware of an emergency in the building by the fire alarm or from a co-worker. You may need to evacuate, even if there is no alarm. Floor Wardens meet at your office floor’s elevator lobby. If you don’t have enough people to perform all roles, you may need to assign roles to staff. Evacuation Procedures All Floor Wardens will need to assemble by their floor’s lobby elevators. If you do not have enough people to fill this role at the timing of this event, you will need to recruit volunteers. The following roles will need to be assigned amongst the Floor Wardens: Searcher Duties: Work in pairs and sweep each wing to make sure everyone is out. Check all enclosed spaces such as bathrooms, storage closets and conference rooms. Close doors as you search. To better aid first responders, Searchers can post sticky blank sticky/post-it notes onto the doors of rooms which they have cleared, indicating to first responders that this room has been cleared of persons. Elevator Duties: Stand by the elevators reminding those exiting not to use the elevator, and to direct them to the stairwells. Be advised that in an emergency; elevators will be unusable! ADA Duties: Move injured and disabled persons to the stairwell area. If you are able to go downstairs, wait for the stairwell to clear of other evacuates before proceeding down. If you are unable to manage stairs, stay with person inside of the stairwell, and send someone down to the first floor to inform the first responders of the situation. The first responder team will determine the best way to get these people to safety. Upon evacuation, all Floor Wardens are to proceed to their designated evacuation area. You must be at least 100 feet away from the building and not in a fire lane or otherwise inhibit first responder vehicular traffic. Any employee who notices something of importance (i.e. trapped person, employee who refuses to leave, building issue, etc.) should report status to any Floor Warden, Fire Department staff, or Life Safety Director. They will need to relay the issue(s), the floor, and its best approximate location. When evacuating use caution when you approach a closed door
Always remain calm. Try to go to a room with an exterior window with a phone and stay there. If this is not an option, find a room with a door and phone. Dial 911, and tell the dispatcher exactly where you are, even if you see fire trucks below. To keep smoke out of your refuge area, use clothing, towels, newspapers, etc. to stuff the cracks around the door and cover the ventilators. Do not break a window; this will bring more smoke into the space. To help rescuers find you, stay in an area where they can see you and wave something bright and light-colored to draw their attention. Above all, think before you act and be patient until help arrives. First responders and rescue efforts will take time, and those who are in the most immediate danger will be prioritized first. | Fire If you smell a suspicious or burning/smoke-like odor, notify Security by dialing 650.838.9700. If you see/smell smoke, see fire, or otherwise confirm that a fire is active, immediately dial 911.
|
MEDICAL EMERGENCY PROCEDURE
|
|
BOMB THREATS/EXPLOSIONS/SUSPICIOUS PACKAGES
|
|
TERRORIST ATTACKS/HOMELAND SECURITY
CHEMICAL ATTACKChemical agents are poisonous vapors, aerosols, liquids and solids that have toxic effects on people, animals or plants. Chemical agents are unlikely to cause death because they dissipate quickly outdoors and are hard to produce. Signs of a chemical release include difficulty breathing, eye irritation, loss of coordination, nausea or burning in the nose, throat and lungs. The presence of many dead insects or birds may indicate a chemical agent release. Before a Chemical Emergency Build an Emergency Supply Kit and include:
Make an Emergency Plan. During a Chemical Attack
After a Chemical Attack Do not leave the safety of a shelter to go outdoors to help others until authorities say it is safe to do so. You will need immediate medical attention from a professional if you are affected by a chemical agent. If medical help is not immediately available, decontaminate yourself and help others decontaminate. Use extreme caution when helping others who have been exposed to chemical agents.
BIOLOGICAL ATTACKMany facilities in communities around the country have received anthrax threat letters. Most were empty envelopes; some have contained powdery substances. The purpose of these guidelines is to recommend procedures for handling such incidents. DO NOT PANIC Anthrax organisms can cause infection in the skin, gastrointestinal system, or the lungs. To do so the organism must be rubbed into abraded skin, swallowed, or inhaled as a fine, aerosolized mist. Disease can be prevented after exposure to the anthrax spores by early treatment with the appropriate antibiotics. Anthrax is not spread from one person to another person. For anthrax to be effective as a covert agent, it must be aerosolized into very small particles. This is difficult to do and requires a great deal of technical skill and special equipment. If these small particles are inhaled, life-threatening lung infection can occur, but prompt recognition and treatment are effective. Suspicious Unopened letter or PACKAGE MARKED WITH THREATENING MESSAGE SUCH AS “ANTHRAX”:
Envelope with powder and powder spills out onto surface:
| QUESTION OF ROOM CONTAMINATION BY AEROSOLIZATION: For example: small device triggered, warning that air-handling system is contaminated, or warning that a biological agent released in a public space.
Source: Center for Disease Control https://emergency.cdc.gov/bioterrorism/ RADIOLOGICAL ATTACK
A Radiological Dispersion Device (RDD) combines a conventional explosive device — such as a bomb — with radioactive material. It is designed to scatter dangerous and sub-lethal amounts of radioactive material over a general area. Such RDDs appeal to terrorists because they require limited technical knowledge to build and deploy compared to a nuclear device. The size of the affected area and the level of destruction caused by an RDD would depend on the sophistication and size of the conventional bomb and other factors. The area affected could be placed off-limits to the public for several months during cleanup efforts.
There is no way of knowing how much warning time there will be before an attack by terrorists using a Radiological Dispersion Device (RDD), so being prepared in advance and knowing what to do and when is important. To prepare for an RDD event, you should do the following:
While the explosive blast will be immediately obvious, the presence of radiation will not be known until trained personnel with specialized equipment are on the scene. If the explosion or radiological release occurs inside, get out immediately and seek safe shelter. Otherwise, if you are:
After finding safe shelter, those who may have been exposed to radioactive material should decontaminate themselves. To do this, remove and bag your clothing (and isolate the bag away from you and others), and shower thoroughly with soap and water. Seek medical attention after officials indicate it is safe to leave shelter. Contamination from an RDD event could affect a wide area, depending on the amount of conventional explosives used, the quantity and type of radioactive material released, and meteorological conditions. Follow these additional guidelines after an RDD event:
|
CIVIL UNREST/DISTURBANCES
|
|
POWER FAILURES
Extended power outages may impact the whole community and the economy. A power outage is when the electrical power goes out unexpectedly. A power outage may:
Go to a community location with power if heat or cold is extreme. | Preparing for a Power Outage Take an inventory of the items you need that rely on electricity. Plan for batteries and other alternative power sources to meet your needs when the power goes out, such as a portable charger or power bank. Have flashlights for every household member. Determine whether your home phone will work in a power outage and how long battery backup will last. Know Your Medical Needs Talk to your medical provider about a power outage plan for medical devices powered by electricity and refrigerated medicines. Find out how long medication can be stored at higher temperatures and get specific guidance for any medications that are critical for life. Food Storage Have enough nonperishable food and water. Keep freezers and refrigerators closed. The refrigerator will keep food cold for about four hours. A full freezer will keep the temperature for about 48 hours. Use coolers with ice if necessary. Monitor temperatures with a thermometer. Throw out food if the temperature is 40 degrees or higher. Using Appliances During Power Outages Install carbon monoxide detectors with battery backup in central locations on every level of your home. Avoid carbon monoxide poisoning. Generators, camp stoves or charcoal grills should always be used outdoors and at least 20 feet away from windows. Never use a gas stovetop or oven to heat your home. Turn off or disconnect appliances, equipment, or electronics. Power may return with momentary surges or spikes that can cause damage. |
SEVERE WEATHER
Severe weather can happen anytime, in any part of the country. Severe weather can include hazardous conditions produced by thunderstorms, including damaging winds, tornadoes, large hail, flooding and flash flooding, and winter storms associated with freezing rain, sleet, snow, and strong winds. LIGHTNING AND THUNDERSTORMSLightning is a leading cause of injury and death from weather-related hazards. Although most lightning victims survive, people struck by lightning often report a variety of long-term, debilitating symptoms. Thunderstorms are dangerous storms that include lightning and can create or cause:
Know Your Risk Know your area’s risk for thunderstorms. In most places they can occur year-round and at any hour. Sign up for your community’s warning system. The Emergency Alert System (EAS) and National Oceanic and Atmospheric Administration (NOAA) Weather Radio also provide emergency alerts. | Strengthen Your Home Cut down or trim trees that may be in danger of falling on your home. Consider buying surge protectors, lightning rods or a lightning protection system to protect your home, appliances and electronic devices. Make an Emergency Plan Create an emergency plan so that you and your family know what to do, where to go and what you will need to protect yourselves from the effects of a thunderstorm. Identify sturdy buildings close to where you live, work, study and play. Stay Safe During Thunderstorms & Lightning If you are under a thunderstorm warning:
|
FLOODS
Flooding is a temporary overflow of water onto land that is normally dry. Floods are the most common natural disaster in the United States. Failing to evacuate flooded areas or entering flood waters can lead to injury or death. Floods may:
Know Your Risk for Floods Visit FEMA's Flood Map Service Center to know types of flood risk in your area. Sign up for your community’s warning system. The Emergency Alert System (EAS) and National Oceanic and Atmospheric Administration (NOAA) Weather Radio also provide emergency alerts. Purchase Flood Insurance Purchase or renew a flood insurance policy. Homeowner’s insurance policies do not cover flooding. It typically takes up to 30 days for a policy to go into effect so the time to buy is well before a disaster. Get flood coverage under the National Flood Insurance Program (NFIP). | Preparing for a Flood Make a plan for your household, including your pets, so that you and your family know what to do, where to go, and what you will need to protect yourselves from flooding. Learn and practice evacuation routes, shelter plans, and flash flood response. Gather supplies, including non-perishable foods, cleaning supplies, and water for several days, in case you must leave immediately or if services are cut off in your area. In Case of Emergency Keep important documents in a waterproof container. Create password-protected digital copies. Protect your property. Move valuables to higher levels. Declutter drains and gutters. Install check valves. Consider a sump pump with a battery. If you are under a flood warning:
|
EARTHQUAKES
Once the shaking starts:
| Floor Wardens should prepare a local condition report. This report should contain:
|
ACTIVE SHOOTER
The below resources are prepared for you and available on the ready.gov website: |
PANDEMIC RESPONSE
A pandemic is a disease outbreak that spans several countries and affects a large number of people. Pandemics are most often caused by viruses, like Coronavirus Disease 2019 (COVID-19), which can easily spread from person to person. A new virus, like COVID-19, can emerge from anywhere and quickly spread around the world. It is hard to predict when or where the next new pandemic will emerge. If a Pandemic is declared:
| Stay Safe During a Pandemic
Continue taking protective actions, like:
Work with your community to talk about the lessons you learned from the pandemic. Decide how you can use these experiences to be more prepared for future pandemics. |
